产品应用
清洗工具
Function | Part Number | Polarity | VDS(V) | RDS(on)(mΩ) | Package |
MOSFET | SDM5041N06LA1 | N | 60 | 4.1 | DFN5060 |
STR900P06LA1 | P | 60 | 90 | TO-252 | |
STM4500C03LA1 | N+P | 30 | 50 | DFN3030-2 | |
STM4115D03LA1 | N+N | 30 | 11.5 | DFN3030-2 | |
SDM5024N04LA1 | N | 40 | 2.4 | DFN5060 | |
Function | Part Number | Polarity | VCEO(V) | IC(A) | Package |
BJT | BC817-40 | NPN | 45 | 0.5 | SOT-23 |
BC807-40 | PNP | 45 | 0.5 | SOT-23 | |
Function | Part Number | Polarity | VRM(V) | IF(A) | Package |
Schottky | SS34A | - | 40 | 3 | SMA |
BAT54 | - | 30 | 0.3 | SOT-23 | |
SS310B | - | 100 | 3 | SMB | |
Function | Part Number | Polarity | Vzonm(V) | IZT(mA) | Package |
Zener | MM1Z3V3 | Uni | 3.3 | 5 | SOD-123 |
Function | Part Number | Polarity | VRM(V) | IF(A) | Package |
Switching | 1N4148W | - | 100 | 0.2 | SOD-123 |
BAV99 | - | 100 | 0.215 | SOT-23 | |
Function | Part Number | Polarity | VRWM(V) | Cj(PF) | Package |
ESD | E3V3SUPC1C | Uni | 3.3 | 30 | DFN1006-2H |
E5V0SBPC1AA | Bi | 5 | 20 | DFN1006-2H | |
E5V0XBPC1A | Bi | 5 | 0.22 | DFN1006-2H | |
Function | Part Number | Polarity | Vwm(V) | Pppm(W) | Package |
TVS | SMAJ Series | - | 5-440 | 400 | SMA |
SMBJ Series | - | 5-440 | 600 | SMB | |
SMCJ Series | - | 5-440 | 1500 | SMC | |
SMFJ Series | - | 5-440 | 200 | SOD-123FL |
